XE Series Explosion-Proof Electric Forklift 1-3.5 t
A 1-3.5 t explosion-proof electric forklift range for warehouse, indoor and outdoor operations, combining electric operation with lift heights of up to 3 m and 48V and 80V battery options for day-to-day material handling.
1-3.5 t
Capacity
Electric
Power
Up to 3 m
Lift Height
Warranty & Support
24 Months / 2,000 Hours Warranty DJJ local after-sales support
NOT SURE IF THIS MODEL FITS YOUR APPLICATION?
Ask the DJJ team to confirm capacity, operating requirements, site conditions and configuration before final selection.
Choosing an Explosion-Proof Electric Forklift: Capacity and Battery
This explosion-proof electric forklift is built for hazardous areas: the brochure marks it Exde(ib)mbs II BT4 Gb and Ex tD(ibD)mbD A21 IP65 T130°C, for gas Zones 1 and 2 and dust Zones 21 and 22. The motors, controller, lights, accelerator, instrument panel and battery are all explosion-proof types. Capacities run from 1,000 to 3,500 kg across six models.
- 1-1.5 t: a 48V/420Ah battery, a 1,900 mm turning radius, 12/13 km/h travel and 13% laden gradeability.
- 2-2.5 t: a 48V/630Ah battery, 2,040-2,090 mm turning radius and 10% gradeability.
- 3-3.5 t: an 80V/500Ah battery, 2,230-2,310 mm turning radius and 10/12 km/h travel.
A 3,000 mm wide-view duplex mast is standard, with full free duplex and triplex masts, a sideshifter, dual or solid tyres and a charger as options. Service weight, including the battery, runs from 3,200 kg on the 1 t model to 5,460 kg on the 3.5 t. Check the certification marking against your site's hazardous area classification before choosing a model.
Practical Features for Daily Operation
Electric Power
Explosion-proof electric design for hazardous gas and dust areas, indoors or outdoors.
Full LED Lighting Set
Headlights, turn, brake, reverse and alarm lights use LED sources in aluminium-alloy casings.
Self-Monitoring System
An onboard control system monitors temperature, brakes and insulation during operation.
Full Specifications
| Capacity | 1-3.5 t |
|---|---|
| Power | Electric |
| Lift Height | Up to 3 m |
| Battery Voltage | 48V / 80V |
| Turning Radius | 1,900-2,310mm |
| Gradeability | Up to 13% |
| Warranty | 24 Months / 2,000 Hours Warranty |
Models in This Series
This series is available in multiple models. Exact availability and technical specifications vary by capacity and configuration.
- CPD10-AC4-Ex
- CPD15-AC4-Ex
- CPD20-AC4-Ex
- CPD25-AC4-Ex
- CPD30-AC4-Ex
- CPD35-AC4-Ex
| Model | Capacity | Battery | Turning radius | Travel laden / unladen | Laden gradeability | Service weight |
|---|---|---|---|---|---|---|
| CPD10-AC4-Ex | 1,000 kg | 48V / 420Ah | 1,900 mm | 12 / 13 km/h | 13% | 3,200 kg |
| CPD15-AC4-Ex | 1,500 kg | 48V / 420Ah | 1,900 mm | 12 / 13 km/h | 13% | 3,200 kg |
| CPD20-AC4-Ex | 2,000 kg | 48V / 630Ah | 2,040 mm | 10 / 13 km/h | 10% | 4,000 kg |
| CPD25-AC4-Ex | 2,500 kg | 48V / 630Ah | 2,090 mm | 10 / 13 km/h | 10% | 4,300 kg |
| CPD30-AC4-Ex | 3,000 kg | 80V / 500Ah | 2,230 mm | 10 / 12 km/h | 10% | 4,850 kg |
| CPD35-AC4-Ex | 3,500 kg | 80V / 500Ah | 2,310 mm | 10 / 12 km/h | 10% | 5,460 kg |
Service weight includes the battery. Standard lift 3,000 mm. Figures from the Hangcha A Series electric explosion-proof forklift brochure (2020).
