Hangcha Rough Terrain Forklift 5-10T
A 5-10 t rough terrain forklift range for outdoor work on uneven ground, with lift heights of up to 6 m and IC drive for load handling where ground conditions shape model selection.
5-10 t
Capacity
IC
Power
Up to 6 m
Lift Height
Warranty & Support
24 Months / 2,000 Hours Warranty DJJ local after-sales support
NOT SURE IF THIS MODEL FITS YOUR APPLICATION?
Ask the DJJ team to confirm capacity, operating requirements, site conditions and configuration before final selection.
Choosing a 5-10 t Rough Terrain Forklift: Capacity and Drive
The Hangcha heavy rough terrain forklift covers 5,000, 7,000 and 10,000 kg at a 600 mm load centre, for heavy loads on unpaved yards and sites. The 5 t and 7 t models are offered in two-wheel and four-wheel drive, while the 10 t model is 4WD only; 4WD versions switch between 2WD and 4WD with one key.
- 5 t: masts up to 6,000 mm, 370 mm of clearance at the wheelbase centre, and a Deutz TCD3.6 at 55.4 kW (Stage V or Stage IIIB) or a Cummins QSF3.8 at 86 kW.
- 7 t: duplex masts up to 5,000 mm, the best laden gradeability in the range at up to 68%, and a Cummins F3.8 at 90 kW (Stage V) or QSF3.8 at 86 kW.
- 10 t: 2,550 mm wide on 17.5-25 front tyres, with 424 mm of clearance, 80 x 160 x 1,520 mm forks and a 5,000 mm maximum lift.
All models have wet brakes, an electro-hydraulic shift, dual air filters, a high-position exhaust and a full-suspension seat. A cab, front windshield, solid tyres, extra hydraulic valves and a -20 °C cold-start battery are optional. Two-wheel drive turns tighter, in 3,550 mm (5 t) and 3,960 mm (7 t) against 4,150 mm and 5,290 mm for 4WD. For loads up to 3.5 t, see the 4WD rough terrain forklift 2.5-3.5 t.
Practical Features for Daily Operation
IC Engine Power
Powertrain tuned for strong engine output at low RPM, for heavy loads on rough ground.
Reinforced Chassis
Strengthened frame and axle layout for heavy lifting on uneven ground.
Separate Brake and Steering
Independent hydraulic circuits for braking and steering reduce interference between systems.
Full Specifications
| Capacity | 5-10 t |
|---|---|
| Power | IC |
| Lift Height | Up to 6 m |
| Ground Clearance | 370-424mm |
| Gradeability | Up to 68% |
| Power / Fuel Type | IC |
| Warranty | 24 Months / 2,000 Hours Warranty |
Models in This Series
This series is available in multiple models. Exact availability and technical specifications vary by capacity and configuration.
- CPCD50
- CPCD70
- CPCD100
| Model | Capacity | Max lift | Ground clearance (centre) | Turning radius | Service weight | Gradeability laden |
|---|---|---|---|---|---|---|
| CPCD50 4WD | 5,000 kg | 6,000 mm | 370 mm | 4,150 mm | 9,050 kg | 45-55% |
| CPCD50 2WD | 5,000 kg | 6,000 mm | 370 mm | 3,550 mm | 9,050 kg | 39-42% |
| CPCD70 4WD | 7,000 kg | 5,000 mm | 387 mm | 5,290 mm | 9,900 kg | 59-68% |
| CPCD70 2WD | 7,000 kg | 5,000 mm | 387 mm | 3,960 mm | 9,900 kg | 52-60% |
| CPCD100 4WD | 10,000 kg | 5,000 mm | 424 mm | 5,740 mm | 15,500 kg | 36-41% |
Rated at a 600 mm load centre. Gradeability ranges cover the engine options. Standard lift 3,000 mm on every model. Figures from the Hangcha 5-10 t two/four-wheel drive rough terrain forklift brochure (2023).
