XH Series 4-Wheel Electric Forklift - Heavy Duty 4-5 t
A 4-5 t 4-wheel electric forklift range for warehouse, indoor and outdoor operations, combining electric operation with lift heights of up to 7 m and Li-ion battery power for day-to-day material handling.
4-5 t
Capacity
Li-ion
Power
Up to 7 m
Lift Height
Warranty & Support
24 Months / 2,000 Hours Warranty DJJ local after-sales support
NOT SURE IF THIS MODEL FITS YOUR APPLICATION?
Ask the DJJ team to confirm capacity, operating requirements, site conditions and configuration before final selection.
Choosing an XH Heavy Duty Electric Forklift 4-5 t
The Hangcha XH Series heavy duty electric forklift runs on a 348V high-voltage lithium iron phosphate battery (173Ah, 60.2 kWh) with CATL cells, and lifts 4,000, 4,500 or 5,000 kg. It charges fully in about 1 hour, or 2 hours on an optional 0.5C charger, and the battery carries a 6-year or 12,000-hour warranty.
- CPD40 and CPD45: 4,000 and 4,500 kg at a 500 mm load centre, with a 2,730 mm turning radius and the best laden gradeability at 30% and 28%.
- CPD50-XHXY2G-W: 5,000 kg at a 500 mm load centre, turning in 2,770 mm.
- CPD50-XHY2G-W: 5,000 kg rated at a longer 600 mm load centre for bulky loads, with a slightly taller lowered mast.
All four travel at 24/25 km/h laden and unladen and lift at up to 480 mm/s laden. The standard lift is 3,000 mm, with triplex masts to 7,000 mm. A multi-function colour instrument, stamped steel body panels and a stainless boarding step are standard, with solid or non-marking tyres, a reversing camera, blue lights and a cold store version as options. For 6-10 t loads, see the XH Series heavy duty electric forklift 6-10 t.
Practical Features for Daily Operation
Electric Power
Electric operation suited to indoor and warehouse environments.
Built for 4-5 t Loads
Capacities of 4-5 t for heavier pallets, with lift heights of up to 7 m.
Turning Radius From 2,730 mm
A turning radius of 2,730-2,770 mm across the range to suit the aisle layout.
Full Specifications
| Capacity | 4-5 t |
|---|---|
| Power | Li-ion |
| Lift Height | Up to 7 m |
| Battery Voltage | 348V |
| Turning Radius | 2,730-2,770mm |
| Gradeability | Up to 30% |
| Warranty | 24 Months / 2,000 Hours Warranty |
Models in This Series
This series is available in multiple models. Exact availability and technical specifications vary by capacity and configuration.
- CPD50
- CPD40
- CPD45
| Model | Capacity | Load centre | Turning radius | Laden gradeability | Service weight |
|---|---|---|---|---|---|
| CPD40-XHY2G-W | 4,000 kg | 500 mm | 2,730 mm | 30% | 6,050 kg |
| CPD45-XHY2G-W | 4,500 kg | 500 mm | 2,730 mm | 28% | 6,250 kg |
| CPD50-XHXY2G-W | 5,000 kg | 500 mm | 2,770 mm | 26% | 6,650 kg |
| CPD50-XHY2G-W | 5,000 kg | 600 mm | 2,770 mm | 25% | 7,000 kg |
Battery 348V / 173Ah lithium (60.2 kWh) on all models. Standard lift 3,000 mm, masts to 7,000 mm. Figures from the Hangcha XH Series heavy duty electric forklift brochure (2025).
