A Series Reach Truck 1.5-1.8 t
A 1.5-1.8 tonne reach truck range for indoor warehouse and narrow-aisle operations, with lift heights of up to 7 m for load handling where storage height, reach and aisle space need to be considered together.
1.5-1.8 t
Capacity
Li-ion
Power
Up to 7 m
Lift Height
Warranty & Support
24 Months / 2,000 Hours Warranty DJJ local after-sales support
NOT SURE IF THIS MODEL FITS YOUR APPLICATION?
Ask the DJJ team to confirm capacity, operating requirements, site conditions and configuration before final selection.
Choosing Between the CQD15 and CQD18 Stand-On Reach Trucks
The A Series 1.5-1.8 t is a stand-on reach truck on a narrow 1,094 mm chassis, built for warehouses with racking up to 7 m. Both of these stand-on reach trucks run on 48V, with a lead-acid battery as standard and a lithium iron phosphate battery on the -I models.
- CQD15 (1,500 kg): the tighter truck, with a 1,600 mm turning radius, 550 mm reach and a 2,666 mm aisle for 1000 x 1200 mm pallets crossways. It holds 1,500 kg up to 4.5 m and 700 kg at 7 m.
- CQD18 (1,800 kg): a 700 mm reach and a 1,750 mm turning radius, needing a 2,715 mm aisle. It holds 1,800 kg up to 4.5 m and 1,050 kg at 7 m.
F2 models are built for cold storage down to -30ยฐC. Both are rated at a 500 mm load centre and travel at up to 10.5 km/h, and a sideshifter reduces capacity by 200 kg. Loads of 2-2.5 tonnes need the A Series reach truck 2-2.5 t.
Practical Features for Daily Operation
Electric Power
Electric operation suited to indoor and warehouse environments.
Reach of 550-700 mm
Reach distances of 550-700 mm to place pallets deep into racking at up to 7 m.
Aisles From 2,666 mm
Minimum aisle widths from 2,666 mm help make the most of warehouse floor space.
Full Specifications
| Capacity | 1.5-1.8 t |
|---|---|
| Power | Li-ion |
| Lift Height | Up to 7 m |
| Minimum Aisle Width | From 2,666mm |
| Turning Radius | 1,600-1,750mm |
| Battery Type / Voltage | Lead-acid / Li-ion, 48V |
| Warranty | 24 Months / 2,000 Hours Warranty |
Models in This Series
This series is available in multiple models. Exact availability and technical specifications vary by capacity and configuration.
- CQD15
- CQD18
| Model | Rated capacity | Max lift | Capacity at max lift | Reach | Aisle (1000 x 1200 crossways) | Turning radius |
|---|---|---|---|---|---|---|
| CQD15-AC5S | 1,500 kg | 7,000 mm | 700 kg | 550 mm | 2,666 mm | 1,600 mm |
| CQD18-AC5S | 1,800 kg | 7,000 mm | 1,050 kg | 700 mm | 2,715 mm | 1,750 mm |
Capacities at a 500 mm load centre without a sideshifter. -I models are lithium, -F2 models are for cold storage. Figures from the Hangcha A Series stand-on reach truck 1.5-1.8 t brochure.
