Hangcha Rough Terrain Forklift 2WD 2.5-3.5T
A 2.5-3.5 t 2WD rough terrain forklift range for outdoor work on uneven ground, with lift heights up to 6 m for load handling where ground conditions guide model selection.
2.5-3.5 t
Capacity
Diesel
Power
Up to 6 m
Lift Height
NOT SURE IF THIS MODEL FITS YOUR APPLICATION?
Ask the DJJ team to confirm capacity, operating requirements, site conditions and configuration before final selection.
Choosing a 2WD Rough Terrain Forklift: Capacity and Engine
The 2026 Hangcha two-wheel drive rough terrain forklift is built on the XF series IC forklift and comes in 2,500, 3,000 and 3,500 kg capacities at a 500 mm load centre. Each capacity is offered with one of three diesel engines, so the choice comes down to the load you lift and the emissions standard your site requires.
- Kubota V2607 (CPCD25/30/35-XW98E-RT2): 47.3 kW, EU Stage V and Tier 4f with a DOC and DPF, and the best laden gradeability at 29-32%.
- Yanmar 4TNE98 (XW33E-RT): 42.1 kW, Stage IIIA and EPA Tier 3, with 22-27% laden gradeability.
- Xinchai 4D32 (XG72E-RT2): 45 kW, with the same 22-27% gradeability as the Yanmar version.
The 2.5 t model is 1,557 mm wide on 12-16.5 front tyres with 235 mm of clearance under the mast, while the 3 t and 3.5 t models move to 14-17.5 tyres and 270 mm. All three share a 2,900 mm turning radius, a suspension hydraulic transmission and a 4-inch colour LCD instrument with CAN bus. The standard lift is 3,000 mm, with duplex masts to 4,500 mm and full free triplex masts to 6,000 mm. For steeper or softer ground at the same capacities, compare the 4WD rough terrain forklift 2.5-3.5 t.
Practical Features for Daily Operation
2WD Rough Terrain Drive
Two-wheel drive with rough terrain tyres for yards, farms and unsealed ground.
High Ground Clearance
235-270 mm ground clearance for working over uneven ground.
Gradeability Up to 32%
Rated for grades of up to 32%; site slope rules still apply.
Full Specifications
| Capacity | 2.5-3.5 t |
|---|---|
| Power | Diesel |
| Lift Height | Up to 6 m |
| Ground Clearance | 235-270mm |
| Gradeability | Up to 32% |
| Power / Fuel Type | Diesel |
Models in This Series
This series is available in multiple models. Exact availability and technical specifications vary by capacity and configuration.
- CPCD25
- CPCD30
- CPCD35
| Model | Capacity | Ground clearance (mast / centre) | Turning radius | Service weight | Travel laden / unladen | Gradeability laden |
|---|---|---|---|---|---|---|
| CPCD25 | 2,500 kg | 235 / 240 mm | 2,900 mm | 4,670 kg | 24 / 26 km/h | 27% (Kubota 32%) |
| CPCD30 | 3,000 kg | 270 / 270 mm | 2,900 mm | 5,120 kg | 26 / 28 km/h | 22% (Kubota 30%) |
| CPCD35 | 3,500 kg | 270 / 270 mm | 2,900 mm | 5,380 kg | 26 / 28 km/h | 22% (Kubota 29%) |
Each capacity is available with a Yanmar 4TNE98 (XW33E-RT), Kubota V2607-CR-TE5B (XW98E-RT2) or Xinchai 4D32XG30-011 (XG72E-RT2) diesel engine. Standard lift 3,000 mm, optional masts to 6,000 mm. Figures from the Hangcha two-wheel drive rough terrain forklift brochure (2026).
