Hangcha Rough Terrain Forklift 2.5-3.5T
A 2.5-3.5 t rough terrain forklift range for outdoor work on uneven ground, with lift heights of up to 6 m for load handling where ground conditions shape model selection.
2.5-3.5 t
Capacity
Electric
Power
Up to 6 m
Lift Height
Warranty & Support
24 Months / 2,000 Hours Warranty DJJ local after-sales support
NOT SURE IF THIS MODEL FITS YOUR APPLICATION?
Ask the DJJ team to confirm capacity, operating requirements, site conditions and configuration before final selection.
Choosing an Electric Rough Terrain Forklift: 2WD or 4WD
The Hangcha high-voltage lithium rough terrain forklift brings battery power to outdoor work on uneven ground. It runs on a 317V/150Ah CATL lithium battery (46.4 kWh) that charges fully in about 1.5 hours, and lifts 2,500, 3,000 or 3,500 kg at a 500 mm load centre. Each capacity comes in two drive layouts.
- RT2 (2WD): a single 30 kW front drive motor, a 2,850 mm turning radius and a 4,635-4,650 mm aisle for 1000 x 1200 mm pallets crossways.
- RT4 (4WD): front and rear drive motors (30 kW and 15 kW), with a 3,300 mm turning radius and a 5,085-5,100 mm aisle.
- Capacity and climbing: gradeability is 63% on the 2.5 t models, 55% on the 3 t and 52% on the 3.5 t, and the 2.5 t lifts fastest at 0.62 m/s laden.
All six models travel at 24/26 km/h laden and unladen on pneumatic tyres, with 225-290 mm of ground clearance and a differential lock as standard. The standard lift is 3,000 mm, with duplex masts to 4,500 mm and full free triplex masts to 6,000 mm. On rough ground capacity drops sharply with height: at 6,000 mm the brochure's rough terrain rating (ISO 22915-13) is only 600-700 kg, so check the mast chart against your heaviest load. A cab, OPS, a reversing camera and solid tyres are optional. For a diesel version, compare the 2WD rough terrain forklift 2.5-3.5 t.
Practical Features for Daily Operation
Electric Dual-Motor Drive
Separate front and rear motors share torque to suit changing ground conditions.
Built for Outdoor Work
Water-cooled motors and controllers manage heat on outdoor sites.
Wide-Base Tyres
Deep-tread tyres, wet brakes and an electronic diff lock for traction on rough ground.
Full Specifications
| Capacity | 2.5-3.5 t |
|---|---|
| Power | Electric |
| Lift Height | Up to 6 m |
| Ground Clearance | 225-290mm |
| Gradeability | Up to 63% |
| Power / Fuel Type | Electric 2WD or 4WD (dual motors on 4WD) |
| Warranty | 24 Months / 2,000 Hours Warranty |
Models in This Series
This series is available in multiple models. Exact availability and technical specifications vary by capacity and configuration.
- CPD25-XY2GE-RT2
- CPD30-XY2GE-RT2
- CPD35-XY2GE-RT2
- CPD25-XY2GC-RT4
- CPD30-XY2GC-RT4
- CPD35-XY2GC-RT4
| Model | Drive | Capacity | Turning radius | Gradeability | Service weight |
|---|---|---|---|---|---|
| CPD25-XY2GE-RT2 | 2WD | 2,500 kg | 2,850 mm | 63% | 5,000 kg |
| CPD30-XY2GE-RT2 | 2WD | 3,000 kg | 2,850 mm | 55% | 5,340 kg |
| CPD35-XY2GE-RT2 | 2WD | 3,500 kg | 2,850 mm | 52% | 5,600 kg |
| CPD25-XY2GC-RT4 | 4WD | 2,500 kg | 3,300 mm | 63% | 5,000 kg |
| CPD30-XY2GC-RT4 | 4WD | 3,000 kg | 3,300 mm | 55% | 5,340 kg |
| CPD35-XY2GC-RT4 | 4WD | 3,500 kg | 3,300 mm | 52% | 5,600 kg |
Battery 317V / 150Ah lithium on all models. Rated at a 500 mm load centre; subtract 200 kg with an integral sideshifter or 300 kg with an external one. Figures from the Hangcha high-voltage lithium battery rough terrain forklift brochure (2023).
