WD Series Pallet Truck 1.5-2 t
A 1.5-2 t pallet truck range for indoor warehouse operations, with lift heights of 120 mm and pedestrian / walkie operator formats for day-to-day pallet movement where travel routes, floor conditions and operator format influence model selection.
1.5-2 t
Capacity
Li-ion / Lead-acid
Power
120 mm
Lift Height
NOT SURE IF THIS MODEL FITS YOUR APPLICATION?
Ask the DJJ team to confirm capacity, operating requirements, site conditions and configuration before final selection.
Choosing a WD Series Pallet Truck Model
The WD Series is a light pedestrian pallet truck for warehouses, supermarkets and workshops, with a built-in charger and a lead-acid battery as standard or lithium on the I models. Choose by load weight and battery type.
- CBD15 (1,500 kg): a 24V brushed DC drive with a 24V/85Ah lead-acid battery, or a 24V/40Ah lithium battery on the CBD15-WD-I.
- CBD20 (2,000 kg): a 48V brushless DC drive with a 48V/56Ah lead-acid battery, or a 48V/20Ah lithium battery on the CBD20-WD-I, and auxiliary wheels as standard for stability on uneven floors and in turns.
Both travel at 4.5 km/h laden, lift 120 mm and turn in 1,374 mm, needing a 1,553 mm aisle for 1000 x 1200 mm pallets crossways. Standard forks are 560 x 1,150 mm, with 680 mm width and 1,220 mm length as options. The multi-function handle shows battery level, hours and error codes, and a weighing scale with printer is optional.
Practical Features for Daily Operation
Electric Power
Electric operation suited to indoor and warehouse environments.
Compact 1,374 mm Turning
A 1,374 mm turning radius for manoeuvring pallets in tight aisles and loading areas.
Walk-Behind Operation
Pedestrian operation with 1,150 mm forks for standard pallet moves on the warehouse floor.
Full Specifications
| Capacity | 1.5-2 t |
|---|---|
| Power | Li-ion / Lead-acid |
| Lift Height | 120 mm |
| Battery Type | Li-ion / Lead-acid |
| Fork Length | 1,150mm |
| Turning Radius | 1,374mm |
Models in This Series
This series is available in multiple models. Exact availability and technical specifications vary by capacity and configuration.
- CBD15
- CBD20
| Model | Capacity | Battery (std) | Laden travel | Laden gradeability | Turning radius | Service weight |
|---|---|---|---|---|---|---|
| CBD15-WD | 1,500 kg | 24V / 85Ah lead-acid | 4.5 km/h | 6% | 1,374 mm | 221 kg |
| CBD15-WD-I | 1,500 kg | 24V / 40Ah lithium | 4.5 km/h | 6% | 1,374 mm | 184 kg |
| CBD20-WD | 2,000 kg | 48V / 56Ah lead-acid | 4.5 km/h | 6% | 1,374 mm | 241 kg |
| CBD20-WD-I | 2,000 kg | 48V / 20Ah lithium | 4.5 km/h | 6% | 1,374 mm | 199 kg |
Rated at a 600 mm load centre. Figures from the Hangcha WD Series pallet truck brochure.
