X Series 4-Wheel Electric Forklift 4-5 t
A 4-5 t 4-wheel electric forklift range for warehouse, indoor and outdoor operations, combining electric operation with lift heights of up to 7 m and Lead-acid battery options for day-to-day material handling.
4-5 t
Capacity
Li-ion / Lead-acid
Power
Up to 7 m
Lift Height
Warranty & Support
24 Months / 2,000 Hours Warranty DJJ local after-sales support
NOT SURE IF THIS MODEL FITS YOUR APPLICATION?
Ask the DJJ team to confirm capacity, operating requirements, site conditions and configuration before final selection.
Choosing an X Series 4-5 t Electric Forklift Model
The X Series 4-5 t is an 80V electric forklift for heavier pallets and outdoor yards, offered with a lead-acid battery as standard or a CATL lithium battery on the -I models. Choose by load weight and load length.
- CPD40 (4 t): the tightest turning radius in the range at 2,540 mm with lead-acid, carrying 2,800 kg at the 7 m maximum lift.
- CPD45 and CPD50 mini (4.5-5 t at 500 mm): a 2,600-2,620 mm turning radius, carrying 3,000-3,200 kg at 7 m.
- CPD50 (5 t at 600 mm): rated at the longer 600 mm load centre for bigger loads, with a 2,680 mm turning radius and 3,600 kg at 7 m.
Laden gradeability is 15-17% and laden travel speed 15.5-16.5 km/h. The lithium -I models are 720-940 kg lighter than the lead-acid versions, and the A version adds anti-corrosion protection for C5 marine and industrial environments. Dual front tyres and solid tyres are available as options.
Practical Features for Daily Operation
Electric Power
Electric operation suited to indoor and warehouse environments.
7 m Lift Height
Lifts 4-5 t loads to heights of up to 7 m for racking and stacking work.
Four-Wheel Chassis
A 4-wheel layout with a turning radius of 2,540-2,680 mm, depending on model.
Full Specifications
| Capacity | 4-5 t |
|---|---|
| Power | Li-ion / Lead-acid |
| Lift Height | Up to 7 m |
| Battery Voltage | 80V |
| Turning Radius | 2,540-2,680mm |
| Gradeability | Up to 20% |
| Warranty | 24 Months / 2,000 Hours Warranty |
Models in This Series
This series is available in multiple models. Exact availability and technical specifications vary by capacity and configuration.
- CPD40
- CPD45
- CPD50
| Model | Capacity | Load centre | Capacity at 7 m | Turning radius (lead-acid / lithium) | Laden gradeability | Service weight (lead-acid / lithium) |
|---|---|---|---|---|---|---|
| CPD40-XC5 / -I | 4,000 kg | 500 mm | 2,800 kg | 2,540 / 2,600 mm | 17% | 6,560 / 5,790 kg |
| CPD45-XC5 / -I | 4,500 kg | 500 mm | 3,000 kg | 2,600 mm | 16% | 6,970 / 6,030 kg |
| CPD50-XXC5 / -I (mini) | 4,990 kg | 500 mm | 3,200 kg | 2,600 / 2,620 mm | 16% | 7,210 / 6,290 kg |
| CPD50-XC5 / -I | 5,000 kg | 600 mm | 3,600 kg | 2,680 mm | 15% | 7,470 / 6,750 kg |
Capacity at 7 m with single front tyres. Figures from the Hangcha X Series 4-5 t brochure.
