X Series All-Directional Reach Truck 2-3 t
A 2-3 t all-directional reach truck range for indoor warehouse and narrow-aisle operations, with lift heights of up to 8.5 m for load handling where storage height, reach and aisle space need to be considered together.
2-3 t
Capacity
Li-ion / Lead-acid
Power
Up to 8.5 m
Lift Height
Warranty & Support
24 Months / 2,000 Hours Warranty DJJ local after-sales support
NOT SURE IF THIS MODEL FITS YOUR APPLICATION?
Ask the DJJ team to confirm capacity, operating requirements, site conditions and configuration before final selection.
Choosing an X Series All-Directional Reach Truck Model
The X Series all-directional reach truck moves long loads such as pipe, timber, sheet and coil through narrow aisles. It has six travel modes: forward, sideways, automatic switching between the two, diagonal crab, 90-degree turns and a 360-degree spin on the spot.
- CCD20 (2,000 kg): the lightest model, with an 80V/300Ah lead-acid or 80V/250Ah lithium battery as standard and 11.5 km/h laden travel. It carries 1,150 kg at the 8.5 m maximum lift.
- CCD25 (2,500 kg): steps up to an 80V/360Ah lead-acid or 80V/346Ah lithium battery and carries 1,250 kg at 8.5 m.
- CCD30 (3,000 kg): the same battery options with the highest capacity at height, 1,500 kg at 8.5 m.
All three share a 1,850 mm wide chassis, 690 mm reach, a 21 kW lift motor and a 2,601 mm aisle for 1,200 x 6,000 mm loads crossways. For loads longer than 3 m, the widened 2,310 mm fork carriage is recommended, which reduces capacity at 8.5 m to 900-1,200 kg. Q models run on lead-acid and IQ models on lithium. If straight, sideways and 360-degree travel is enough, compare the X Series 4-way reach truck.
Practical Features for Daily Operation
Electric Power
Electric operation suited to indoor and warehouse environments.
All-Directional Travel
All-directional travel helps position loads in narrow aisles from 2,601 mm wide.
690 mm Reach
A 690 mm reach and lift heights of up to 8.5 m for loading and unloading racking.
Full Specifications
| Capacity | 2-3 t |
|---|---|
| Power | Li-ion / Lead-acid |
| Lift Height | Up to 8.5 m |
| Minimum Aisle Width | From 2,601mm |
| Turning Radius | 1,450-1,873mm |
| Battery Type / Voltage | Li-ion / Lead-acid, 80V |
| Warranty | 24 Months / 2,000 Hours Warranty |
Models in This Series
This series is available in multiple models. Exact availability and technical specifications vary by capacity and configuration.
- CCD20
- CCD25
- CCD30
| Model | Rated capacity | Capacity at 8.5 m | Capacity at 8.5 m (widened carriage) | Lead-acid battery (Q) | Lithium battery (IQ) | Laden travel speed |
|---|---|---|---|---|---|---|
| CCD20-XC4-Q / IQ | 2,000 kg | 1,150 kg | 900 kg | 80V / 300Ah | 80V / 250Ah | 11.5 km/h |
| CCD25-XC4-Q / IQ | 2,500 kg | 1,250 kg | 1,000 kg | 80V / 360Ah | 80V / 346Ah | 11 km/h |
| CCD30-XC4-Q / IQ | 3,000 kg | 1,500 kg | 1,200 kg | 80V / 360Ah | 80V / 346Ah | 10.5 km/h |
Capacities at a 600 mm load centre. Standard lift 4,000 mm, triplex masts to 8,500 mm. Figures from the Hangcha X Series all-directional reach truck brochure.
