XA Series Double Pallet Stacker - Double Deck 2 t

  • Indoor
  • Warehouse

A 2 tonne double pallet stacker range for indoor warehouse operations, with lift heights of up to 2.01 m for pallet movement and stacking where load, lift height and operating space need to be matched.

2 t

Capacity

Li-ion / Lead-acid

Power

Up to 2.01 m

Lift Height

Warranty & Support

12 Months / 2,000 Hours Warranty DJJ local after-sales support

NOT SURE IF THIS MODEL FITS YOUR APPLICATION?
Ask the DJJ team to confirm capacity, operating requirements, site conditions and configuration before final selection.

Choosing the XA Series Double-Deck Stacker: Lead-Acid or Lithium

The XA Series double-deck stacker carries two pallets at once on long runs, with a stand-on platform and a folding seat so the operator can stand or sit side-on. Unlike a standard pallet stacker, it works in three modes: pallet truck, stacker and double pallet.

  • Capacity: 2,000 kg on the support arms and 1,000 kg on the mast, with 125 mm initial lift and mast lift up to 2,010 mm.
  • Lead-acid or lithium: a 24V/375Ah lead-acid battery (297 kg) or a 24V/230Ah lithium battery (80 kg), giving a service weight of 1,310 kg or 1,205 kg.
  • Speed: 10 km/h laden and 12 km/h unladen with S, P and E speed modes, and 6% laden gradeability.

The truck is 760 mm wide with a 2,002-2,070 mm turning radius and needs a 2,480 mm aisle for 1000 x 1200 mm pallets. The battery rolls out sideways as standard for quick swaps, and ramp anti-rollback is fitted. The X Series double stacker comes in walk-behind and stand-on versions on a 48V battery.

Practical Features for Daily Operation

Electric Power

Electric operation suited to indoor and warehouse environments.

Double-Deck Handling

A double-deck design moves stacked pallet loads, with lift heights up to 2.01 m.

Aisles From 2,480 mm

Pedestrian and walkie operation in aisles from 2,480 mm wide, carrying up to 2 t.

Full Specifications

Capacity2 t
PowerLi-ion / Lead-acid
Lift HeightUp to 2.01 m
Battery Type / VoltageLi-ion / Lead-acid, 24V
Minimum Aisle WidthFrom 2,480mm
Turning Radius2,002-2,070mm
Warranty12 Months / 2,000 Hours Warranty

Models in This Series

This series is available in multiple models. Exact availability and technical specifications vary by capacity and configuration.

  • CDD20
VersionBatteryService weightLaden / unladen travelLaden gradeabilityTurning radiusAisle (1000 x 1200 crossways)
Lead-acid24V / 375Ah (297 kg)1,310 kg10 / 12 km/h6%2,002 / 2,070 mm2,480 mm
Lithium (I)24V / 230Ah (80 kg)1,205 kg10 / 12 km/h6%2,002 / 2,070 mm2,480 mm

2,000 kg on the support arms and 1,000 kg on the mast, at a 600 mm load centre.
