S35 Max
The Yuchai S35 Max is a 1.6 tonne electric skid steer for indoor and outdoor applications, combining a 0.35 t rated operating capacity, 0.29 m³ bucket and 3,245 mm maximum operating height.
0.35 t
Capacity
17 kW combined
Power
1.6 t
Weight
Warranty & Support
5 Years / 20,000 Hours Battery Warranty · 1 Year / 2,000 Hours Structural Components Warranty DJJ local after-sales support
NOT SURE IF THIS MODEL FITS YOUR APPLICATION?
Ask the DJJ team to confirm capacity, operating requirements, site conditions and configuration before final selection.
Choosing the S35 Max Over the S35 Pro
The Yuchai S35 Max is the long-endurance version of the S35 electric skid steer, with a 29.17 kWh lithium iron phosphate battery for 8-9 hours of continuous work. This electric skid steer has a 350 kg rated operating capacity, a 0.29 m³ bucket and a 730 kg tipping load.
- Against the S35 Pro: the Pro uses a 21.29 kWh battery for 6-8 hours and weighs 80 kg less, with identical power, hydraulics and dimensions.
- Charging: 30% to 80% in 1 hour, so the battery can be topped up during a break.
- Size: 959 mm wide, 1,815 mm to the top of the cab and a 1,650 mm turning radius, for narrow corridors, alleys and low-height areas.
Wheel-side drive motors with automatic hold give up to 10.5 km/h, and the 20.5 L/min hydraulic system at 33.7 MPa runs loading, sweeping and crushing attachments. For a smaller battery and a lighter machine, see the S35 Pro skid steer.
Practical Features for Daily Operation
Electric Power
Battery-electric drive with braking energy recovery, for indoor and outdoor work.
Wheel-Side Motors
A motor at each wheel replaces the chain drive, with fewer parts to wear.
Fewer Service Items
No engine oil, fuel filters or chain drive to maintain.
Full Specifications
| Capacity | 0.35 t |
|---|---|
| Power | 17 kW combined |
| Weight | 1.6 t |
| Bucket Capacity | 0.29 m³ |
| Max Operating Height | 3,245 mm |
| Bucket Breakout Force | 8 kN |
| Warranty | 5 Years / 20,000 Hours Battery Warranty · 1 Year / 2,000 Hours Structural Components Warranty |
Models in This Series
This series is available in multiple models. Exact availability and technical specifications vary by capacity and configuration.
- S35 Max
| Model | Battery | Run time | Operating weight | Tipping load | Rated operating capacity | Fast charge |
|---|---|---|---|---|---|---|
| S35 Pro | 21.29 kWh lithium | 6-8 h | 1,540 kg | 700 kg | 350 kg | 30-80% in 1 h |
| S35 Max | 29.17 kWh lithium | 8-9 h | 1,620 kg | 730 kg | 350 kg | 30-80% in 1 h |
Both models share the same motors, hydraulics, bucket and dimensions. Figures from the S35 Pro / S35 Max electric skid steer brochure.
