A Series Diesel Forklift 4-5.5 t
A 4-5.5 t diesel forklift range for outdoor operations, with lift heights of up to 7 m and Diesel power options for material handling where load, lift height and site conditions guide model selection.
4-5.5 t
Capacity
Diesel
Power
Up to 7 m
Lift Height
NOT SURE IF THIS MODEL FITS YOUR APPLICATION?
Ask the DJJ team to confirm capacity, operating requirements, site conditions and configuration before final selection.
Choosing an A Series Diesel Forklift 4-5.5 t
The Hangcha A2 Series 4-5.5 t diesel forklift lifts 4,000, 4,500, 5,000 or 5,500 kg at a 500 mm load centre, with a powershift transmission and travel at 24/25 km/h laden and unladen. Each capacity comes with one of two diesel engines.
- Xinchai 4D35 (G53): 60 kW at 2,200 rpm, meeting China off-road Stage III, with up to 25% laden gradeability on the 4 t model.
- Mitsubishi S6S (W76): 52 kW at 2,300 rpm and Stage IIIA, with 20-24% laden gradeability.
- Size: 1,420 mm wide on the 4 t model and 1,490 mm on 4.5-5.5 t, with turning radii from 2,780 to 2,900 mm.
The standard lift is 3,000 mm and masts reach 7,000 mm, with 7.5 m and 8 m available on dual front wheels. Vacuum-assisted brakes, a Class III (IV) fork carriage, LED lights, a maintenance reminder and an air filter with a safety element are standard, and a cab, heater, solid tyres and dual drive wheels are optional. For lighter loads, see the A Series diesel forklift 1.5-3.8 t.
Practical Features for Daily Operation
Diesel Engine
Xinchai or Mitsubishi engine options, running on diesel.
Lift Heights to 7 m
Masts reaching up to 6.42 m for higher outdoor stacking and truck loading.
Gradeability to 50%
Pneumatic tyres and gradeability of up to 50% for ramps and outdoor yard surfaces.
Full Specifications
| Capacity | 4-5.5 t |
|---|---|
| Power | Diesel |
| Lift Height | Up to 7 m |
| Engine | XINCHAI / MITSUBISHI |
| Tyre Type | Pneumatic |
| Gradeability | Up to 25% |
Models in This Series
This series is available in multiple models. Exact availability and technical specifications vary by capacity and configuration.
- CPCD40
- CPCD45
- CPCD50
- CPCD55
| Model | Capacity | Width | Turning radius | Laden gradeability (Xinchai / Mitsubishi) | Service weight (Xinchai / Mitsubishi) |
|---|---|---|---|---|---|
| CPCD40 | 4,000 kg | 1,420 mm | 2,780 mm | 25% / 24% | 5,970 / 5,970 kg |
| CPCD45 | 4,500 kg | 1,490 mm | 2,820 mm | 23% / 22% | 6,220 / 6,420 kg |
| CPCD50 | 5,000 kg | 1,490 mm | 2,820 mm | 20% / 20% | 6,500 / 6,750 kg |
| CPCD55 | 5,500 kg | 1,490 mm | 2,900 mm | 20% / 20% | 6,900 / 6,900 kg |
Rated at a 500 mm load centre. Standard lift 3,000 mm, masts to 7,000 mm. Figures from the Hangcha A2 Series 4-5.5 t diesel forklift brochure (2025).
