A Series End-Control Rider Pallet Truck 2.7-3.6 t
A 2.7-3.6 t end-control rider pallet truck range for indoor warehouse operations, with lift heights of 150 mm for day-to-day pallet movement where travel routes, floor conditions and operator format influence model selection.
2.7-3.6 t
Capacity
Li-ion
Power
150 mm
Lift Height
Warranty & Support
12 Months / 2,000 Hours Warranty DJJ local after-sales support
NOT SURE IF THIS MODEL FITS YOUR APPLICATION?
Ask the DJJ team to confirm capacity, operating requirements, site conditions and configuration before final selection.
Choosing Between the ECR27Li and ECR36Li End-Control Riders
The A Series end-control rider is a stand-on pallet truck for long runs across warehouses and docks, travelling at 9 km/h laden and 14 km/h unladen. A picking button on the tiller lets the operator drive from beside the truck for faster order picking.
- ECR27Li (2,700 kg): for standard pallets on long runs.
- ECR36Li (3,600 kg): for heavier pallets, with 8% laden gradeability.
Both are rated at a 610 mm (24 in) load centre, lift 150 mm and are 910 mm wide with a 2,035 mm turning radius. They run on a 25.6V/230Ah lithium iron phosphate battery with an on-board charger, or 460Ah as an option, and 2,438 mm or 3,658 mm forks are available for moving two or three pallets at once. A parking brake and anti-slide function stop the truck rolling on a grade. For a walk-behind version, see the A Series walkie pallet truck.
Practical Features for Daily Operation
Electric Power
Electric operation suited to indoor and warehouse environments.
Long Forks Optional
Optional fork lengths of 2,438-3,658 mm, with a 150 mm lift height for pallet moves.
Walk or Ride Operation
Walk/ride end-control operation for short moves or longer travel across the floor.
Full Specifications
| Capacity | 2.7-3.6 t |
|---|---|
| Power | Li-ion |
| Lift Height | 150 mm |
| Battery Type | Li-ion |
| Fork Length | 2,438 or 3,658mm (optional) |
| Turning Radius | 2,035mm |
| Warranty | 12 Months / 2,000 Hours Warranty |
Models in This Series
This series is available in multiple models. Exact availability and technical specifications vary by capacity and configuration.
- CBD27
- CBD36
| Model | Capacity | Load centre | Laden / unladen travel | Turning radius | Width | Battery (std) |
|---|---|---|---|---|---|---|
| ECR27Li | 2,700 kg | 610 mm | 9 / 14 km/h | 2,035 mm | 910 mm | 25.6V / 230Ah |
| ECR36Li | 3,600 kg | 610 mm | 9 / 14 km/h | 2,035 mm | 910 mm | 25.6V / 230Ah |
Figures from the Hangcha A Series end-control rider pallet truck brochure (HC Forklift America).
