Hangcha HS Series Rough Terrain Scissor Lift PMSM
A rough terrain scissor lift range for outdoor work on uneven ground, with working heights up to 18.2 m and platform capacities of 150-680 kg for access work at height.
370-680 kg
Capacity
Electric
Power
Up to 18.2 m
Working Height
Warranty & Support
12 Months / 2,000 Hours Warranty DJJ local after-sales support
NOT SURE IF THIS MODEL FITS YOUR APPLICATION?
Ask the DJJ team to confirm capacity, operating requirements, site conditions and configuration before final selection.
Choosing an HS Series Electric Rough Terrain Scissor Lift
The HS Series PMSM rough terrain scissor lift brings outdoor scissor work onto battery power: an 80V/210Ah lithium battery (19 kWh, CATL cells) drives a permanent magnet motor that uses 8-10% less energy than an AC asynchronous motor. Hydraulic outriggers level the machine at the push of a button.
- HS1218RP and HS1418RP: 12-14.2 m working height on a 1.74 m wide chassis with a 2.8 x 1.6 m deck, carrying 450 kg and 370 kg.
- HS1523RP and HS1823RP: 15.1-18.2 m working height on a 2.28 m wide chassis, with a 3.96 x 1.82 m deck that extends both ways and carries 680 kg, with up to 230 kg on the extension.
The motor is sealed to IP67 and withstands pressure washing, a floating axle keeps all four wheels on the ground, and an overload alarm stops lifting. The lithium battery carries a 6-year or 12,000-hour warranty, and a backup power supply allows emergency descent. For a diesel model with up to 1,150 kg capacity, see the HS Series diesel rough terrain scissor lift.
Practical Features for Daily Operation
PMSM Electric Drive
Permanent magnet synchronous motor drive for efficient outdoor work.
Up to 18.2 m Working Height
Working height of up to 18.2 m, with gradeability of up to 50%.
Large Work Platform
A 2.8 m by 1.6 m platform with capacity of 150-680 kg by model.
Full Specifications
| Capacity | 370-680 kg |
|---|---|
| Power | Electric |
| Working Height | Up to 18.2 m |
| Platform Size | 3.96 x 1.82m / 2.8 x 1.6m |
| Drive Type | Electric |
| Gradeability | Up to 50% |
| Warranty | 12 Months / 2,000 Hours Warranty |
Models in This Series
This series is available in multiple models. Exact availability and technical specifications vary by capacity and configuration.
- HS1218RP
- HS1418RP
- HS1523RP
- HS1823RP
| Model | Working height | Capacity (deck / extension) | Deck size | Width | Gradeability | Weight |
|---|---|---|---|---|---|---|
| HS1218RP | 12 m | 450 / 150 kg | 2.8 x 1.6 m | 1.74 m | 40% | 4,500 / 4,000 kg |
| HS1418RP | 14.2 m | 370 / 150 kg | 2.8 x 1.6 m | 1.74 m | 40% | 5,300 / 4,800 kg |
| HS1523RP | 15.1 m | 680 / 230 kg | 3.96 x 1.82 m | 2.28 m | 50% | 8,000 kg |
| HS1823RP | 18.2 m | 680 / 230 kg | 3.96 x 1.82 m | 2.28 m | 40% | 8,600 kg |
The brochure lists two weights for the HS1218RP and HS1418RP without explaining the difference. Figures from the Hangcha rough terrain scissor lift (PMSM) brochure (2025).
