X Series Diesel Forklift 38-48 t
A 38-48 t diesel forklift range for outdoor operations, with lift heights of up to 7 m and Diesel power options for material handling where load, lift height and site conditions guide model selection.
38-48 t
Capacity
Diesel
Power
Up to 7 m
Lift Height
NOT SURE IF THIS MODEL FITS YOUR APPLICATION?
Ask the DJJ team to confirm capacity, operating requirements, site conditions and configuration before final selection.
Choosing an X Series 38-48 t Diesel Forklift
The Hangcha X Series 38-48 t diesel forklift is the heaviest model in the range: 38, 40, 46 and 48 t at a 1,200 mm load centre, all powered by 265 kW Volvo engines through a DANA TE-30 transmission with five forward and three reverse gears.
- Volvo TAD1181VE (XRH17): EU Stage V.
- Volvo TAD1151VE (XRW86): Stage IIIA / Tier 3.
- Grades and speed: 25% laden gradeability on 38-46 t and 22% on the 48 t, with 22-24 km/h laden and up to 28 km/h unladen.
Every model has a 4,215 mm overall width, a 7,500 mm turning radius and a 4,120 mm cab height, so check access routes and door openings before delivery. The standard lift is 4,000 mm and masts reach 7,000 mm. Service weight runs from 55,000 kg on the 38 t to 63,000 kg on the 48 t. For 20-35 t loads, see the X Series diesel forklift 20-35 t.
Practical Features for Daily Operation
Volvo Engine Power
Volvo engine power for very heavy 38-48 t loads in outdoor yards.
38-48 t Heavy Capacity
Rated capacities of 38-48 t for very heavy outdoor loads, with lift heights up to 7 m.
Pneumatic Tyre Grip
Pneumatic tyres and gradeability of up to 25% for sloping and unsealed outdoor sites.
Full Specifications
| Capacity | 38-48 t |
|---|---|
| Power | Diesel |
| Lift Height | Up to 7 m |
| Engine | VOLVO |
| Tyre Type | Pneumatic |
| Gradeability | Up to 25% |
Models in This Series
This series is available in multiple models. Exact availability and technical specifications vary by capacity and configuration.
- CPCD380
- CPCD400
- CPCD460
- CPCD480
| Model | Capacity | Turning radius | Travel laden / unladen | Laden gradeability | Service weight |
|---|---|---|---|---|---|
| CPCD380 | 38,000 kg | 7,500 mm | 24 / 28 km/h | 25% | 55,000 kg |
| CPCD400 | 40,000 kg | 7,500 mm | 23 / 28 km/h | 25% | 56,000 kg |
| CPCD460 | 46,000 kg | 7,500 mm | 23 / 27 km/h | 25% | 61,500 kg |
| CPCD480 | 48,000 kg | 7,500 mm | 22 / 27 km/h | 22% | 63,000 kg |
Rated at a 1,200 mm load centre. Each capacity is available with Volvo TAD1181VE (Stage V) or TAD1151VE (Stage IIIA) engines. Figures from the Hangcha X Series 38-48 t diesel forklift brochure (2026).
Everything You Need After the Product Decision
DJJ support continues beyond the initial equipment decision, with local teams available to help with service, parts and ongoing equipment support.
