XC Series Electric Cushion Tyre Forklift 3.5-5.5 t
A 3.5-5.5 t electric cushion tyre forklift range for indoor warehouse operations, combining electric operation with lift heights of up to 6 m for day-to-day material handling.
3.5-5.5 t
Capacity
Electric
Power
Up to 6 m
Lift Height
NOT SURE IF THIS MODEL FITS YOUR APPLICATION?
Ask the DJJ team to confirm capacity, operating requirements, site conditions and configuration before final selection.
Choosing an XC Series 3.5-5.5 t Electric Cushion Tyre Forklift
The XC Series 3.5-5.5 t electric cushion tyre forklift is the mid-size lithium iron phosphate truck in Hangcha's North American range, sold there as the FB35CLi, FB45CLi and FB55CLi. Capacities of 3,500, 4,500 and 5,500 kg (8,000-12,000 lb) are rated at a 600 mm (24 in) load centre.
- CPD35 (FB35CLi): the narrowest at 1,200 mm, with a 2,140 mm turning radius, the best laden gradeability at 23% and the fastest laden lift at 370 mm/s.
- CPD45 (FB45CLi): 4,500 kg on wider 22x12-16 front tyres, 1,350 mm wide with a 2,220 mm turning radius.
- CPD55 (FB55CLi): 5,500 kg with a larger 80V/684Ah battery as standard and a 906Ah (72.48 kWh) option for longer shifts.
The CPD35 and CPD45 use an 80V/604Ah (48.32 kWh) battery. All three have a 23 kW AC drive motor and a 28 kW AC pump motor, travel at up to 18.5 km/h and lift 3,000 mm as standard, with full free lift triplex masts to 6,000 mm. LED lights, a multi-function instrument cluster and smooth cushion tyres are standard, with permanent magnet motors, a reverse camera and blue lights as options. For 6-7 t loads, see the XC Series electric cushion tyre forklift 6-7 t.
Practical Features for Daily Operation
Electric Power
Electric operation suited to indoor and warehouse environments.
Cushion Tyre Chassis
Cushion tyres and a 2,140-2,420 mm turning radius suit smooth warehouse floors and aisles.
Lift Heights to 6 m
Lift heights of up to 6 m for racking and block stacking of 3.5-5.5 t loads.
Full Specifications
| Capacity | 3.5-5.5 t |
|---|---|
| Power | Electric |
| Lift Height | Up to 6 m |
| Tyre Type | Cushion tyre |
| Overall Width | 1,200-1,350mm |
| Turning Radius | 2,140-2,420mm |
Models in This Series
This series is available in multiple models. Exact availability and technical specifications vary by capacity and configuration.
- CPD35
- CPD45
- CPD55
| Model | Rated capacity (600 mm / 24 in) | Battery | Width | Turning radius | Gradeability laden | Service weight |
|---|---|---|---|---|---|---|
| CPD35-XD2-CSI (FB35CLi) | 3,500 kg (8,000 lb) | 80V / 604Ah | 1,200 mm | 2,140 mm | 23% | 6,000 kg |
| CPD45-XD2-CSI (FB45CLi) | 4,500 kg (10,000 lb) | 80V / 604Ah | 1,350 mm | 2,220 mm | 19% | 6,980 kg |
| CPD55-XD2-CSI (FB55CLi) | 5,500 kg (12,000 lb) | 80V / 684Ah (906Ah optional) | 1,350 mm | 2,420 mm | 16% | 8,050 kg |
Standard lift 3,000 mm, triplex masts to 6,000 mm. Kilogram figures as printed in the brochure. Figures from the Hangcha XC Series 3.5-5.5 t electric cushion tyre forklift brochure (2025).
Everything You Need After the Product Decision
DJJ support continues beyond the initial equipment decision, with local teams available to help with service, parts and ongoing equipment support.
