X Series Diesel & LPG Forklift 4-5 t
A 4-5 t diesel & LPG forklift range for outdoor operations, with lift heights of up to 8 m and Diesel / LPG power options for material handling where load, lift height and site conditions guide model selection.
4-5 t
Capacity
Diesel / LPG
Power
Up to 8 m
Lift Height
Warranty & Support
24 Months / 2,000 Hours Warranty DJJ local after-sales support
NOT SURE IF THIS MODEL FITS YOUR APPLICATION?
Ask the DJJ team to confirm capacity, operating requirements, site conditions and configuration before final selection.
Choosing an X Series 4-5 t Model: Diesel or LPG/Petrol
The X Series 4-5 t comes in two fuel versions with the same dimensions: diesel with a Mitsubishi S6S engine, or dual fuel with a PSI 4.3L engine that runs on LPG or petrol. Choose the capacity first, then the fuel by how steep your site is.
- 4 t: the tightest turning radius at 2,700 mm and the narrowest body at 1,420 mm, with a 4,450 mm aisle for 1000 x 1200 mm pallets crossways.
- 4.5-5 t: a 1,490 mm wide body and 150 mm wide forks, with a 2,720-2,780 mm turning radius.
- Diesel or LPG/petrol: the PSI 4.3L dual-fuel engine gives 25-30% laden gradeability and 37.2 kN drawbar pull, against 20-25% and 31.64 kN for the Mitsubishi diesel.
Optional diesel engines from Xinchai, UD and Perkins are listed, and an Okamura transmission is available with the Mitsubishi engine. All models have a powershift transmission with two forward speeds and are rated at a 500 mm load centre with a 3,000 mm standard lift. Triplex masts reach 7 m, with 7.5 m or 8 m optional. For 1.5-3.8 t loads, see the X Series diesel and LPG forklift 1.5-3.8 t.
Practical Features for Daily Operation
Diesel or LPG Engine
Mitsubishi, PSI, Xinchai or Perkins engine options, including common-rail diesel.
Lift Heights to 8 m
Lift heights of up to 8 m on pneumatic tyres for outdoor stacking and loading.
Fault Alert Display
An LCD screen shows real-time data and fault alerts, with an enlarged hood for inspection.
Full Specifications
| Capacity | 4-5 t |
|---|---|
| Power | Diesel / LPG |
| Lift Height | Up to 8 m |
| Engine | MITSUBISHI / PSI / XINCHAI / UD / PERKINS |
| Tyre Type | Pneumatic |
| Gradeability | Up to 30% |
| Warranty | 24 Months / 2,000 Hours Warranty |
Models in This Series
This series is available in multiple models. Exact availability and technical specifications vary by capacity and configuration.
- CPCD40
- CPCD45
- CPCD50
- CPQYD40
- CPQYD45
- CPQYD50
| Model | Capacity | Fuel | Turning radius | Aisle (1000 x 1200 crossways) | Laden gradeability | Service weight |
|---|---|---|---|---|---|---|
| CPCD40-XRW76 | 4,000 kg | Diesel | 2,700 mm | 4,450 mm | 25% | 6,200 kg |
| CPCD45-XRW76 | 4,500 kg | Diesel | 2,720 mm | 4,470 mm | 22% | 6,400 kg |
| CPCD50-XRXW76 | 5,000 kg | Diesel | 2,780 mm | 4,535 mm | 20% | 6,750 kg |
| CPQYD40-XRW57 | 4,000 kg | LPG / petrol | 2,700 mm | 4,450 mm | 30% | 6,200 kg |
| CPQYD45-XRW57 | 4,500 kg | LPG / petrol | 2,720 mm | 4,470 mm | 27% | 6,400 kg |
| CPQYD50-XRXW57 | 5,000 kg | LPG / petrol | 2,780 mm | 4,535 mm | 25% | 6,750 kg |
Rated at a 500 mm load centre with the standard 3,000 mm mast. Figures from the Hangcha X Series diesel / gasoline / LPG brochure (4-5 t).
