XF Series Diesel Forklift 8-12 t
An 8-12 t diesel forklift range for outdoor operations, with lift heights of up to 7 m and Diesel power options for material handling where load, lift height and site conditions guide model selection.
8-12 t
Capacity
Diesel
Power
Up to 7 m
Lift Height
Warranty & Support
24 Months / 2,000 Hours Warranty DJJ local after-sales support
NOT SURE IF THIS MODEL FITS YOUR APPLICATION?
Ask the DJJ team to confirm capacity, operating requirements, site conditions and configuration before final selection.
Choosing an XF Series 8-12 t Diesel Forklift: Capacity and Engine
The Hangcha XF Series heavy diesel forklift lifts 8,000, 10,000 or 12,000 kg at a 600 mm load centre. Each capacity is offered with three engine versions, so you can match the emissions standard to your site.
- Deutz TCD3.6 Stage V (XW96G): 85 kW, the cleanest option.
- Deutz TCD3.6 Stage IV (XW75G): 85 kW.
- 6BG1 engine (XW41B): 97.7 kW, the most powerful version, with its emission class printed as G2.
The standard lift is 3,000 mm. The 8 t and 10 t models reach 7,000 mm with an optional triplex mast, while the 12 t model tops out at 6,500 mm. The overhead guard stands 2,580 mm high, the truck is 2,165 mm wide, and laden gradeability is over 20%. Turning radius grows from 3,630 mm on the 8 t to 4,040 mm on the 12 t. For a dedicated 12 t model rated for 28% gradeability, compare the X Series diesel forklift 12 t.
Practical Features for Daily Operation
Deutz Engine Power
Deutz engine power for 8-12 t loads in outdoor yards.
Full Floating Cabin
A full floating seat and cabin with an engine damper to cut vibration for the operator.
Easy-Reach Service Points
Engine oil dipstick, hydraulic filter and water separator are placed for quick checks.
Full Specifications
| Capacity | 8-12 t |
|---|---|
| Power | Diesel |
| Lift Height | Up to 7 m |
| Engine | DEUTZ / ISUZU |
| Tyre Type | Pneumatic |
| Gradeability | Over 20% |
| Warranty | 24 Months / 2,000 Hours Warranty |
Models in This Series
This series is available in multiple models. Exact availability and technical specifications vary by capacity and configuration.
- CPCD80
- CPCD100
- CPCD120
| Model | Capacity | Max lift | Turning radius | Unladen travel | Service weight |
|---|---|---|---|---|---|
| CPCD80 | 8,000 kg | 7,000 mm | 3,630 mm | 28.5 km/h | 11,200 kg |
| CPCD100 | 10,000 kg | 7,000 mm | 3,940 mm | 28.5 km/h | 13,000 kg |
| CPCD120 | 12,000 kg | 6,500 mm | 4,040 mm | 27 km/h | 14,300 kg |
Rated at a 600 mm load centre. Each capacity is available with a Deutz TCD3.6 (Stage IV or Stage V, 85 kW) or a 6BG1 engine (97.7 kW). 7,000 mm requires the optional triplex mast. Figures from the Hangcha XF Series 8-12 t internal combustion forklift brochure (2022).
